RS PRO Plunger Limit Switch, NO/NC, IP66, DPST, Zinc Alloy Housing, 400V ac Max, 10A Max
Documentos Técnicos
Especificações
Brand
RS ProActuator Type
Plunger
Pole and Throw Configuration
DPST
Normal State Configuration
NO/NC
IP Rating
IP66
Maximum Current
10A
Housing Material
Zinc Alloy
Maximum AC Voltage
400V
Maximum DC Voltage
250V
Connection Type
Cable
Action Type
Snap Action
Length
30.3mm
Depth
32.5mm
Width
75mm
Maximum Operating Temperature
+70°C
Minimum Operating Temperature
-25°C
Mounting Orientation
Vertical
Operating Force
15 N
Mechanical Life
15000000Operations
País de Origem
Italy
Detalhes do produto
RS M20 AM F/T Series Limit Switches
Easy to use electromechanical limit switches offer special qualities and purpose built detection devices with characteristics such as, presence/absence, positioning and travel limit, objects passing and counting. These limit switches are made from zinc alloy (Zamack) and all have a degree of protection of IP 66 or a Plastic casing IP65.
Approvals
IEC 947-5-1, EN 60 947-5-1
