Sharp PT480E 13 ° IR Phototransistor, Through Hole 2-Pin Side Looker package
Documentos Técnicos
Especificações
Brand
SharpSpectrums Detected
Infrared
Typical Fall Time
3.5µs
Typical Rise Time
3µs
Maximum Dark Current
1000nA
Angle of Half Sensitivity
13 °
Polarity
NPN
Number of Pins
2
Mounting Type
Through Hole
Package Type
Side Looker
Dimensions
3 x 2.95 x 21.5mm
Collector Current
20mA
Width
2.95mm
Spectral Range of Sensitivity
Maximum of 900 nm
Maximum Wavelength Detected
900nm
Length
3mm
Height
21.5mm
Minimum Wavelength Detected
800nm
Detalhes do produto
PT480 Series Phototransistors
The PT480 family, from Sharp, are a family of narrow acceptance phototransistors. They are in side looking (SL) epoxy resin packages with a domed lens on the side of the package. The PT480F devices have a black plastic package which offers a daylight blocking filter while the PT480 has a clear lens for visible and near IR radiation.
IR Phototransistors, Sharp
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Informações de estoque temporariamente indisponíveis.
Verifique novamente mais tarde.
R$ 12,73
Each (Sem VAT)
1
R$ 12,73
Each (Sem VAT)
1
Comprar em grandes quantidades
| Quantidade | Preço unitário |
|---|---|
| 1 - 19 | R$ 12,73 |
| 20+ | R$ 8,27 |
