TE Connectivity PCB Mount Power Relay, 12V dc Coil, 12A Switching Current, SPDT

Nº de Estoque RS: 256-3121Marca: TE ConnectivityPart Number: 5-1393239-4Distrelec Article No.: 13721173
brand-logo
Ver tudo em Power Relays

Documentos Técnicos

Especificações

Brand

TE Connectivity

Coil Voltage

12V dc

Contact Configuration

SPDT

Mounting Type

PCB Mount

Switching Current

12A

Number of Poles

1

Series

RT1

Latching

No

Terminal Type

Through Hole

Maximum Switching Voltage AC

400V ac

Length

29mm

Coil Resistance

360Ω

Coil Power

400mW

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+85°C

Isolation Coil To Contact

5kVrms

Depth

12.7mm

Height

15.7mm

Contact Material

Silver Alloy

Maximum Switching Power AC

3 kVA

Application

Power

País de Origem

Austria

Detalhes do produto

Power PCB relay, RT relay, 8 A, 2-pin switching, 10 A, 12 A and 16 A, 1-pin, switching
