GIC 2AAD Series DIN Rail Mount Timer Relay, 24 → 240V ac/dc, 2-Contact, 0.1 s → 10h, DPDT

Nº de Estoque RS: 818-4579Marca: GICPart Number: 2AADT5
brand-logo
Ver tudo em Timer Relays

Documentos Técnicos

Especificações

Brand

GIC

Supply Voltage

24 → 240V ac/dc

Mounting Type

DIN Rail

Mode of Operation

Asymmetric OFF/ON, Asymmetric ON/OFF

Time Range

0.1 s → 10h

Number of Contacts

2

Number of Timer Functions

Multi Function

Contact Configuration

DPDT

Time Increment

Hours, Seconds

Maximum Current

5A

Maximum Voltage

240V ac/dc

Switch Configuration

DPDT

Terminal Type

Screw

Power Supply

External

Width

22.5mm

Minimum Voltage

24V ac/dc

Length

75mm

Series

2AAD

Maximum Operating Temperature

+60°C

Depth

100.5mm

Minimum Operating Temperature

-10°C

Time Delay

200ms

País de Origem

India

Detalhes do produto

GIC Asymmetrical Recycling Timer

Micon 175 Series Asymmetric & Multifunction Timers provide the user with a comprehensive range of timing functions to suit a wide variety of applications. Thanks to the highly versatile Timer voltage range the Micon 175 series can be installed into new and existing applications hassle free

Standards

UL94-V0 Flame Retardent Enclosure

Multifunction
