Jumo QUANTROL Panel PID Temperature Controller 1 Input, 2 Output Analogue 240V ac On-Off
Documentos Técnicos
Especificações
Brand
JumoProduct Type
PID Temperature Controller
Output Type
Analogue
Number of Inputs
1
Number of Outputs
2
Maximum Current
3A
Minimum Operating Temperature
-5°C
Maximum Operating Temperature
55°C
Terminal Type
Screw
Control Type
On-Off
Maximum Supply Voltage
240V ac
Firing Mode
Firing curve for pottery kilns
Digital Comms
RS485 Modbus RTU
Diagnostics
Yes
Maximum Voltage
230V
Display Type
LED
Length
48mm
Standards/Approvals
UL 61010-1, IEC 61554, DIN EN 61326-1, DIN EN 61010-1, DIN EN 60529, CAN/CSA C22.2 No. 61010-1
IP Rating
IP65
Series
QUANTROL
Mount Type
Panel
Input Type
Universal
Panel Depth
95mm
País de Origem
Germany
Detalhes do produto
Quantrol LC-Series - PID Controller
The Jumo Quantrol is a compact, easy to use, and self-optimizing controller series.
The controller is used for two-state and three-state control applications as well as for the control of regulating valves or SCR power controllers via a continuous controller output.
The universal analog input is for RTD temperature probes, thermocouples, or current / voltage signals and can be programmed by the user.
Informações de estoque temporariamente indisponíveis.
R$ 5.582,36
R$ 5.582,36 Each (Sem VAT)
1
R$ 5.582,36
R$ 5.582,36 Each (Sem VAT)
Informações de estoque temporariamente indisponíveis.
1
