Keithley Data Acquisition Coupler for Use with 2750 Series, 2700 Series, 2701 Series Multiplexer Module

Nº de Estoque RS: 796-2646Marca: KeithleyPart Number: 7703Distrelec Article No.: 30108851
brand-logo
Ver tudo em Acessório de Aquisição de Dados

Documentos Técnicos

Especificações

Brand

Keithley

Product Type

Data Acquisition Coupler

Accessory Type

Multiplexer Module

For Use With

2750 Series, 2700 Series, 2701 Series

Detalhes do produto

Keithley 7703 32-channel High Speed Differential Multiplexer Module

The Keithley 7703 plug-in module offers 32 channels of 2-pole multiplexer switching or 16 channels of 4-pole multiplexer switching that can be configured as two independent banks of multiplexers. Non-latching reed relays provide high speeds and are designed for 300 volt, 500 mA; 10VA. The relay closures are stored in onboard memory. Module uses include RTD and thermistor temperature applications. The 7703 is for use with Keithley systems 2700 ( 760-0354 , 7600357 ), 2701 ( 760-0351 ) and 2750 ( 760-0360 ).

Supplied with

Mating connectors (2) with solder cup (Model 7788)

Keithley 7700 20-channel Differential Multiplexer Module
