Microchip AT89S51-24PU, 8bit 8051 Microcontroller, AT89S, 24MHz, 4 kB Flash, 40-Pin PDIP
Documentos Técnicos
Especificações
Brand
MicrochipFamily Name
AT89S
Package Type
PDIP
Mounting Type
Through Hole
Pin Count
40
Device Core
8051
Data Bus Width
8bit
Program Memory Size
4 kB
Maximum Frequency
24MHz
RAM Size
128 B
USB Channels
0
Number of SPI Channels
0
Number of USART Channels
0
Number of UART Channels
1
Number of I2C Channels
0
Typical Operating Supply Voltage
4 to 5.5 V
Number of CAN Channels
0
Minimum Operating Temperature
-40 °C
Height
4.445mm
Number of LIN Channels
0
Dimensions
52.578 x 13.97 x 4.445mm
Program Memory Type
Flash
Number of Ethernet Channels
0
Number of PCI Channels
0
Maximum Operating Temperature
+85 °C
Length
52.58mm
Width
13.97mm
Instruction Set Architecture
CISC
