onsemi Silicon Junction, Single, 2 A, 2-Pin 1 kV DO-41 MUR2100EG
Documentos Técnicos
Especificações
Brand
onsemiDiode Configuration
Single
Product Type
Silicon Junction
Maximum Forward Current If
2A
Sub Type
Silicon Junction
Mount Type
Through Hole
Package Type
DO-41
Pin Count
2
Maximum Forward Voltage Vf
2.2V
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
35A
Peak Reverse Recovery Time trr
100ns
Maximum Peak Reverse Repetitive Voltage Vrrm
1kV
Maximum Operating Temperature
175°C
Length
5.2mm
Height
5.2mm
Width
2.7 mm
Diameter
2.7 mm
Standards/Approvals
No
Automotive Standard
No
Detalhes do produto
Rectifier Diodes, 2A to 3A, ON Semiconductor
Standards
Products with NSV- or SUR-prefixed Manufacturer Part Nos are AEC-Q101 automotive qualified.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Informações de estoque temporariamente indisponíveis.
R$ 221,00
R$ 8,84 Each (In a Pack of 25) (Sem VAT)
Padrão
25
R$ 221,00
R$ 8,84 Each (In a Pack of 25) (Sem VAT)
Informações de estoque temporariamente indisponíveis.
Padrão
25
